Description
Marine lifejacket light a sort of supporting the use of life jackets life jackets lights, including power, light holder, lamp holder, bulb and shade, lamp and lamp clip embedded joint, which is characterized by the shade of the front have described the main lens, the front side a ring of the auxiliary lens, set away from the hole on the lamp, lamp set on the folder from the rod holder, set the folder from the poles are set from the bar. The utility model Lifejacket light Lifejacket light to reduce the power capacity of existing conditions, able to increase the irradiation direction of the luminous intensity, due to the irradiation direction of the center of the periphery and a halo, an increase of the night drowning people the chance to be discovered. Marine Lifejacket light Lifejacket light composition generally includes marine power, light holder, lamp holder, bulb and shade, light clip and holder for embedded joints, characterized in that shade the front have described the main lens, the front side of a ring shaped auxiliary convex lens, set away from the hole on the lamp, lamp set on the folder from the rod holder, set the folder from the poles are set from the bar.
Our ship, lifejacket light Lifejacket light) Specifications
DFYD-LA, DFYD-L-B1 lifejacket light DFYD-L-B2 Lifejacket light Lifejacket light DFYD-LB
Lifejacket light luminous intensity ≧ 0.75cd
Lifejacket light hours ≧ 8h
Voltage DFYD-LA lifejacket light as 2.9V, DFYD-LB Lifejacket light of 6V
Light in the form DFYD-LA lifejacket light as Always, DFYD-LB Lifejacket light to flash
Lifejacket light ambient temperature storage
30 ℃ ~ ~ +65 ℃
Lifejacket light working environment temperature -1 ℃ ~ ~ +30 ℃
DFYD-LB lifejacket light flash frequency of 50 to 70 beats / min
Life jacket light life jacket light color is white
New DFYD-L-B Lifejacket light
Lifejacket light utility model patent No.: 200520140402.8
Lifejacket light design patent number: 200530171860.3
Lifejacket light production license: XK18-102-00016
My company produce a series of life-saving lamps series have been certified for CCS, in line with MSC81 (70) standard. Can be assured the assembly.
